4Pipes·Wall and floor seals
Penetration seal Pressio, plug
Gas-tight and watertight plug that seals casing pipes during casting into concrete. Rubber element is compressed between pressure plates for a secure seal.
Delivered by
About the product
The penetration seal provides a gas-tight and watertight seal between the medium and the casing pipe when pipes are cast into concrete. Rubber element is compressed between pressure plates. | Material: EPDM rubber Stainless steel bolt Stainless steel pressure plates Working temperature: -55°C - +204°C | Max pressure: 5.0 bar. (from 3 bar axial anchoring is required)
Benefits
- Radon-tight sealing of boreholes and casing pipes
- Gas-tight and watertight even at pressures up to 5 bar
Variants(11)
Click a row for all details, or + to add it to the quote request.
Material specification
| Component | Material |
|---|---|
| Sealing element (rubber 2x40 mm) | EPDM |
| Bolt | Stainless |
| Pressure plates | Stainless steel |
Certifieringar & standarder
EN 13501-1
